Hypertrophic pulmonary osteoarthropathy with esophageal sarcomatoid carcinoma: a case report

Introduction

Hypertrophic osteoarthropathy (HOA) is a syndrome caused by thickening of soft tissue around the bone and extensive periosteal new bone formation, its age of onset is mainly middle-aged and old people (1). The main clinical manifestations are clubbing fingers (toes) and extensive periosteal hyperplasia of the long bone (1). This disease can be divided into two types—primary HOA that is also called familial HOA and secondary HOA that often has obvious visceral diseases, the most of which is lung, is also known as hypertrophic pulmonary osteoarthropathy (HPOA) (2). Sarcomatoid carcinoma is rare in esophageal carcinoma. Its biological behavior and prognosis are different from other common esophageal carcinoma pathologic types—esophageal squamous carcinoma and adenocarcinoma (3,4). So HPOA in esophageal sarcomatoid carcinoma is rare. Our study aims to describe and discuss the clinical feature, imaging, pathological features, and treatment of the rare case. We present the following article in accordance with the CARE reporting checklist (available at http://dx.doi.org/10.21037/apm-20-1309).

Case presentation

A 48-year-old male has difficulty swallowing, choking with food, and chest and back pain in August 2018. No improvement after 1-month reating pharyngitis. At the beginning of September 2018, the fingers and toes began to hypertrophy (Figure 1A), and there was no tenderness or increased skin temperature. Single-photon emission computed tomography (SPECT) bone scan showed increased radioactivity in the long bone cortex and joints of the four limbs (Figure 1B) and it was considered as HPOA. His pulmonary function test revealed a large extrapolated volume, insufficient explosive power, and a platform of the expiratory curve (Figure 2), which conformed to the possibility of intrathoracic or fixed upper airway obstruction. And he had decreased forced vital capacity (FVC) with normal forced the first second of expiratory volume (FEV1) and normal total lung capacity (TLC), which was consistent with obstructive ventilation dysfunction. Finger oxygen was 95–96%. Before that, Upper digestive tract radiography revealed that the mucosa was damaged about 7.7 cm in the middle thoracic esophagus, irregular niches were seen, and the local lumen was expanded (Figure 3A). Computed tomography (CT) revealed solid mass in the root of lower neck (Figure 3B), the side of esophagus, tracheoesophageal groove, 4L and 8 section of mediastinal lymph nodes, and the side of cardia, the largest of which invaded the pericardium and the root of pulmonary vein and was 3.8×2.4×6.6 cm³ and, in the middle thoracic esophagus (Figure 3C). Ultrasonography also revealed abnormal cervical lymph nodes with low echo. Endoscopy (Figure 4A) with biopsy and endoscopic ultrasonography (Figure 4B) revealed that a protuberant mass, mainly located in the intrinsic myometrium and penetrated the outer membrane esophagus, was about 27–36 cm from the incisor with unclear boundary with surrounding tissues. In addition, hyperemia and coarseness of the left pyriform fossa were also observed by endoscopy with biopsy. Hematoxylin and eosin (HE) staining and Vimentin immunohistochemical staining of the esophagus tissue and HE staining of the left pyriform fossa indicated sarcomatoid carcinoma(Figure 5A,B) and squamous cell carcinoma (Figure 5C), respectively. SPECT bone scan and abdominal CT failed to show evidence of other distant metastasis and special exceptions. No tumor markers were remarkable. The patient’s medical history did not show evidence of carcinoma or other disease and any family member had not been diagnosed with carcinoma. This patient has been smoking and drinking for 27 years, with about 20 cigarettes and 300 g white wine per day, and has now quit smoking and drinking for one month. His Karnofsky Performance Status (KPS) grade was 80 and blood routine and blood biochemical test was normal. Based on the above results, the final diagnosis was esophageal sarcomatoid carcinoma and squamous cell carcinoma of pyriform fossa with HPOA, and the tumor node metastasis (TNM) classification was cT4N1M1b in esophageal sarcomatoid carcinoma and cT1N0M0 in squamous cell carcinoma of pyriform fossa, which corresponds to at least American Joint Committee on Carcinoma (AJCC) Stage IVB and I respectively. The patient received concomitant chemoradiotherapy from October to December 2018, including 5 cycles of chemotherapy (paclitaxel liposome 60 mg day 1 and nedaplatin 30 mg day 1, q1w) and 6MV-X/VMAT-95%PGTV 59.92 Gy/2.14 Gy/28 F and 95%PTV 50.4 Gy/1.8 Gy/28 F. Re-examination revealed the abnormal left supraclavicular lymph node is larger than the former. Then He received 6 cycles of chemotherapy (paclitaxel liposome 210 mg day 1 and nedaplatin 50 mg day 1, 60 mg day 2, q3w) from January 2020 to May 2020. During this period, the patient returned to the hospital in time according to the treatment course and did regular reexamination according to the doctor’s advice. Regular re-examination every two or three months from June 2019 when showed stable disease and normal finger oxygen, but the clubbing has not been relieved. Now the patient remains in a stable condition. During concurrent radiotherapy and chemotherapy, the patient had a degree I radiation dermatitis which included skin redness, swelling and desquamation in the radiotherapy area, mild radiation esophagitis which included dysphagia and slight swallowing pain, and other adverse reactions also appeared in the chemotherapy alone such as poor appetite, nausea, and fatigue, but the blood routine, blood biochemistry, and all kinds of vital signs are all in the normal range. For the above adverse reactions, we have not made medical treatment but comfort the patient, according to CTCAE 5.0. All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient.

Figure 1 Clinical manifestations and SPECT examination. (A) Clubbing of the fingers and toes. Symmetric clubbing was found in the fingers (left and middle) and toes (right). (B) Technetium-99m labeled MDP (methyl diphosphonate) bone scan of the whole body shows increased uptake at the hands, feet, proximal humerus, proximal femur, and tibia bilaterally.

Figure 2 Pulmonary function test. (A) Diffusion function curve. (B) Time volume curve. (C) Flow-volume curve.

Figure 3 Masses and enlarged lymph nodes. (A) In the esophagogram, the mucosa is damaged about 7.7 cm in the middle thoracic esophagus, and irregular niches were seen. (B) CT scans of the trunk. A solid mass in the root of the lower neck. (C) CT scans of the trunk. A large mass (3.8×2.4×6.6 cm³) extends from the esophagus pressing the root of the pulmonary vein and invading the pericardium and diffusely involving surrounding tissues.

Figure 4 Endoscopic findings of the esophageal mass and hypopharyngeal abnormality. (A) Endoscopy shows that the mucosa of the left pyriform fossa is congested and rough, and a protuberant mass is in the esophagus about 27–36 cm from the incisor. The surface of the mass is broken and eroded, covered with a large amount of white moss. The mass is fragile and easy to bleed. The esophageal lumen with abnormal stenosis in the mass is difficult to pass through by endoscopy, but it still can do. The remaining esophageal mucosa was rough and obvious and shows a piebald lesion in iodine staining. (B) Endoscopic ultrasonography shows that the lesion is mainly located in the intrinsic muscle layer of the esophageal wall and penetrates the outer membrane of the esophageal wall with a close relationship with the surrounding tissue and unclear boundary. Abnormally enlarged lymph nodes are in the tracheoesophageal groove and beside the cardia.

Figure 5 Pathological examination. Histopathological findings of the tumor. HE staining (A) and immunostaining of Vimentin (B) shows that spindle cells. HE staining (C) shows diffuse dark-brownish deposition at the cytoplasmof the spindle tumor cells. (A) ×200. (B) left ×100; middle ×200; right ×400. (C) ×200.

Discussion

Pierre Marie and Eugen von Bamberger first described secondary HOA in 1890 and 1891, which often associated with pulmonary diseases like lung carcinoma, cystic fibrosis, or pulmonary tuberculosis (2). HPOA in malignancy, the most common is lung carcinoma (2). The association of esophageal sarcomatoid carcinoma and HPOA is extremely rare: no medical case report found in a PUBMED search in the indexed English-language literature, although there have been some reports about HPOA and other pathologic types of esophageal carcinoma in the past 20 years (5-10) (Table 1). In these reports, all esophageal carcinoma patients with HPOA were male and 66.7% of them were non-epithelial esophageal carcinoma. Although there is no statistical analysis report on the relationship between esophageal carcinoma and HPOA, esophageal non-epithelial carcinoma seems more likely to cause HPOA according to the table. In this case, the primary tumor was in the middle thoracic esophagus, causing HPOA, for the following reasons. On the one hand, a constriction induced by the tumor in pulmonary vein contributed to the decrease of pulmonary artery blood flow, causing pulmonary capillary oxygen reduction, on the other hand, the intrathoracic fixation mass itself interfered respiration for increasing respiratory muscle load and occupying part of the intrapleural volume (11). Furthermore, tumor invading pericardium resulted in increased myocardial movement load and decreased ejection fraction (12). These adverse effects on the lung and heart obtained by the tumor indicated the insufficiency of blood and oxygen supply in the four limbs, manifesting clubbing fingers (toes) (2). Sarcomatoid carcinoma of epithelial origin, also called spindle cell carcinoma, with both epithelial (carcinomatous) and stromal (sarcomatoid) components, showed a biphasic appearance on histology. These spindle-shaped cells located in an undifferentiated matrix with high malignant potential, are commonly arranged in heliciform or fasciculus (4). The rare pathologic type with an approximate incidence of 0.3–2% in esophageal malignancy (4,13), has been reported in some articles or case concentrated on pathological research (4,13-15). All the reported patients were without HPOA.

Table 1 HPOA associated with primary esophageal carcinoma
Full table

Compared with esophageal cancer, HPOA is more common in lung cancer (16). HPOA incidence in cases of primary lung carcinoma in the USA published in the 1980s put the occurrence at 0.8% (17). In recent years, Cruz et al. have reported a male Afro-descendant 57-year-old patient was bronchial adenocarcinoma with HPOA and abnormal antinuclear antibodies and anti-Sm antibodies (18). The clinical symptoms of HPOA are caused by tumors, which are easily misdiagnosed as autoimmune diseases. We should pay attention to this point in the diagnosis and treatment in all kinds of thoracic cancer combined with HPOA.

The rate of locoregional metastasis was 33–65% and the tumor doubling time was 2.2–5 months in esophageal sarcomatoid carcinoma (13,14,19). Regional lymph nodes followed by lungs and pleura were commonly involved. It preferentially metastasized to the lymphatics in a rapid and aggressive manner but showed a better prognosis than esophageal squamous cell carcinoma. The 5-year survival in Stage III/IV was 16.2% and radical resection with lymphadenectomy was the first treatment way for operable patients with esophageal sarcomatoid carcinoma (13). Our patient had no opportunity of surgery after surgical evaluation so that chemoradiotherapy with a conventional division of radical dose is the most appropriate first-time treatment for him in view of KPS 80 and no fundamental disease.

The patient’s condition has been effectively controlled by chemotherapy and radiotherapy, but the five-year survival rate of patients with advanced esophageal carcinoma is still very low under the existing traditional treatment methods, and the adverse reactions also contribute to low life quality. We look forward to the breakthrough of immunotherapy and molecular targeting therapy to improve the situation.

Although the patient had lost the opportunity of operation when he went to see a doctor, after concurrent chemoradiotherapy and multicycle chemotherapy, the patient is now in a stable condition with KPS 70. Now, he is particularly satisfied with the treatments. As the mainstay of the family, although he can no longer bear the heavy work, he can at least spend an uneventful but precious time with his family and accompany his child to grow up.

Based on our report, although HPOA associated with primary esophageal sarcomatoid carcinoma is a rare disease, it should not be underestimated.
