Multi-nodule of large airway: tracheobronchopathia osteochondroplastica

Introduction

Tracheobronchopathia osteochondroplastica (TO) is a rare benign disease with a stable or indolent course, which is characterized by the formation of multiple cartilaginous or osseous submucosal nodules that originate from the cartilaginous rings of the airway projecting into the tracheobronchial lumen, spare the posterior membranous wall, causing hoarseness, persistent and/or productive cough, hemoptyses, dyspnea and some other symptoms (1). The misdiagnosis and missed diagnosis are very common for its variable and non-specific clinical presentation, especially in the early stage of the disease, which can be asymptomatic. TO is usually discovered by accident. The diagnosis rate has been increased significantly with the development of CT, bronchoscopy techniques, and improved awareness. However, there are no standard guidelines for TO management, and most studies about TO were case reports or small series. Thus, the present study aimed to enhance the knowledge and describe the diagnosis and treatment strategy of TO by analyzing the clinical data of 19 patients with TO retrospectively.

We present the following article in accordance with the STROBE reporting checklist (available at http://dx.doi.org/10.21037/apm-20-316).

Methods

Study design and data collection

The trial was conducted in accordance with the Declaration of Helsinki (as revised in 2013). This study was approved by the ethics committee of The Second Affiliated Hospital of Air Force Medical University (No.2013027). All of the subjects signed the informed consent form before they underwent bronchoscopic inspection. Because of the retrospective nature of the study, informed consent on human research was not obtained from the participants. Waiver of consent to use the patient records was granted by the Institutional Review Board, and analysis of this study was carried out after anonymization of the patients’ data.

A total of 32,215 subjects had taken bronchoscopic examination between January 2014 and December 2018 in the Department of Respiratory and Critical Care Medicine of The Second Affiliated Hospital of Air Force Medical University. 19 patients were identified as TO with histopathologic findings and 2 pulmonary physicians who had more than 5 years of experience in bronchoscopy. Medical records of these patients including demographics, clinical presentations, bronchoscopic and histopathologic features, managements and outcomes were retrospectively analyzed. All patients were followed up for 2 years.

According to the classification criteria developed in a large Chinese cohort study by the characteristic bronchoscopic image (2), TO was divided into three stages: The bronchoscopic visualization of stage I (early stage, also a mild grade) exhibits mucosa hyperemia edema and yellow-whitish soft lesions with plaque-like infiltrations covering the lumen mucosa scatteredly; stage II (middle stage, moderate grade) reveals cartilaginous nodules and sessile spicules protruding into the lumen dispersedly or diffusely with a cobblestone or stalactite appearance; stage III demonstrates airway narrowness even obstruction with a deformed and rigid tracheal wall.

Statistical analysis

Continuous variables are described by using mean ± SD. Categorical variables are described as number (percentage). Categorical variables (<5) were analyzed with Fisher’s exact test and continuous variables were assessed by Student t-test. The significance level of statistical tests was set at P<0.05. All statistical analyses were conducted using R version 3.5.1.

Results

Among the 32,215 patients, 19 (male, 13; overall rate, 0.06%) were diagnosed as TO. The age ranged from 16 to 65 years old (the average age, 47.42±12.12 y; male vs. female, P=0.52). Among the 19 patients, 6 had a history of chronic, recurrent bronchitis or pneumonia. One had been misinterpreted as asthma. Two subjects were suffered from cancer concomitantly (one in lung adenocarcinoma, and the other in postoperative thyroid gland cancer). Two had esophageal disease (One in gastritis and reflux esophagitis, and the other in leucoplakia of esophageal mucosa). Two had been previously diagnosed with infectious disease (one in chronic hepatitis B, and the other in tuberculosis). One had porokeratosis and one had gout.

The most frequent manifestation was chronic cough (15/19). Other clinical complaint included sputum production (7/19), dyspnea on exertion (12/19), hemoptysis (4/19), chest tightness and pain (4/19), continuous or intermittent fever (6/19), dryness of the throat (1/19), hoarseness (1/19). What is more, 2 patients were asymptomatic. Abnormal findings on chest auscultation such as wheezing and stridor were found in 3 patients.

In the light of the bronchoscopic manifestations, patients were categorized as three groups as shown in Figure 1: the largest proportion in the current research was group of Stage II incorporating 10 subjects, followed by stage III (5 subjects) and stage I (4 subjects), respectively.

Figure 1 Imaging of TO in different stages. CT scans of TO in stage I (A,D), stage II (B,E), stage III (C,F). Bronchoscopic image of TO in stage I (G), stage II (H), stage III (I). TO, tracheobronchopathia osteochondroplastica.

Twelve subjects underwent chest CT in our hospital and 1 in other hospital as shown in Figure 1. Submucosal calcifications were present in 8 individuals (61.54%), sparing the posterior membranous trachea. Among which 3 (23.07%) showed annular or linear calcification along the inner lining of the tracheobronchial wall, thickening of the tracheobronchial wall, but the tracheobronchial wall remained smooth; 5 (38.46%) presented with rough tracheobronchial wall and main tracheobronchial stenosis with multiple irregular calcified nodules protruding into the lumen. 1 (7.70%) displayed irregular thickening of the tracheal wall with no calcification and the other 4 (30.77%) had no abnormal findings in the tracheal wall and lumen. The positive rate of CT in stage I, stage II and stage III was 0, 50%, 100%, respectively (stage I vs. stage II, P=0.22; stage II vs. stage III, P=0.11; stage I vs. stage III, P=0.01).

Histopathological analysis, as shown in Figure 2, presented inflammatory exudation, squamous metaplasia of the ciliated columnar of respiratory epithelium. Cartilaginous and osseous deposited in the underlying submucosa, accompanied by fibrous tissue proliferation, mineralized acellular protein matrix and chronic inflammation cell infiltration.

Figure 2 Histopathological findings of TO. Squamous metaplasia of the bronchial mucosa, infiltration of chronic inflammatory cells in the bronchial mucosa, cartilaginous and osseous deposition underneath the respiratory epithelium (bar in A and C: 300 µm; bar in B and D: 100 µm). TO, tracheobronchopathia osteochondroplastica.

One subject in stage III with sever obstruction in the tracheal and four in stage II underwent repeated bronchoscopic intervention such as argon plasma coagulation regularly for 6 to 24 months, among which, the patient in stage III also received balloon dilatation. Additionally, two subjects in stage III and two in stage II were administered inhaled corticosteroids involving Budesonide and Formoterol Fumarate for Inhalation (160 µg/4.5 µg, bid) or Salmetero Xinafoate and Fluticasone propionate Powder for Inhalation (50 µg/250 µg, bid), with duration of treatment varying from 3 to 24 months. Improvement of cough, dyspnea and performance status were observed, however little change was found under bronchoscopy and patient in stage III receiving argon plasma coagulation and balloon dilatation progressed two years later whose bronchoscopic finding displayed bilateral main bronchi stenosis. The lung cancer patient received regular chemotherapy and died one year later, and the other patient took antibiotics, expectorant, antitussive and some other symptomatic treatments showing stable bronchoscopically.

Discussion

TO was originally described in 1857 by Wilks, who reported autoptic findings of a number of bony plates in a 38-year-old man who died of tuberculosis (3). Ecchondrosis and exostosis proposed by Virchow in 1869 and metaplasia of the elastic tissue by Aschoff in 1910 had been considered as two main theories illuminating the origin and pathogenesis of TO (4,5), which is currently listed under the osteochondrodysplasia category. The incidence rate of TO ranged from 1:400 (0.25%) to 3:1,000 (0.30%) in autopsies and 1:125 (0.80%) to 1:10,000 (0.01%) via bronchoscopy (6). The detection rate of this disease in the current study by bronchoscopy was 0.06%, which is consistent with previous reports.

At present, the etiology and pathogenesis of TO have not been fully understood. Coexistence of TO with sarcoidosis, pulmonary adenocarcinoma, breast cancer, esophageal cancer, IgA deficiency and tuberculosis had been reported (7-10). In the current study, we described two TO patients concomitant with lung adenocarcinoma and thyroid gland cancer, respectively. Perhaps there is a similar potential etio-pathogenetic mechanism between TO and malignant diseases, because abnormal bone metabolism is common in cancer especially those with neuroendocrine or endocrine features. Researchers reported TO occurred in recurrent retrosternal goiter, demonstrating an association between TO and thyroid pathology further (11). Adenovirus, coxsackie B virus were also found in TO (12), and in our study we presented TO coexisted with tuberculosis and HBV, supporting chronic infection or inflammation may play a crucial role in the occurrence or exacerbation of TO. Some TO patients were smokers, or suffered from reflux esophagitis or had a long-term exposure to dust or irritant gases due to occupational factors, so gastric acid, smoking, dust and irritant gases should also be considered as pathogenic factors. Overall, TO may be attributed to chronic infection or inflammation, cancer, physical and chemical factors, smoking and some other factors.

Chest X-ray is generally normal and there are not typical radiological signs. CT scans showed poor detection rate of TO patients in stage I, which can reveal the characteristic of TO-related tracheobronchial lesions for its sensitivity to calcification. Nevertheless, some radiologist just ignore this sign due to their lack of awareness of TO. So improving awareness is of significant importance for radiologist. Characteristic chest CT scans of TO demonstrate multiple calcified nodules at the anterolateral wall of the trachea with typical sparing of the posterior membranous part (13). Positive percentage of CT in the current study (9/13) was lower than that of Luo’s study, which was 87.5% (28/32). Proportion of cases who didn’t undergo CT scans may explain the difference between Luo’s study (41/73) and ours (6/19). Additionally, CT image of three-dimensional airway reconstruction should also be taken into consideration. CT virtual bronchoscopy, as a non-invasive technique, could also be applied to detect the characteristic manifestations of TO, which resembles stalactites, or manifests with a rock-garden-like trachea (14).

Bronchoscopy is the gold standard for TO diagnosis. However multi-nodule abnormalities of the tracheobronchus under bronchoscopy was caused by different diseases, 29% of which were diagnosed as tuberculosis granuloma, and 41.8% were malignant disease, and 21.8% were TO, and 3.6% were sarcoidosis, and 1.8% lymphoma, 1.8% fungal infection in An’s study (15). Conventional bronchoscopy is insufficient for the detection of subtle mucosal changest and treatment responses. Autofluorescence imaging bronchoscopy (AFI) is a newly developed advanced endoscopic technology identifying subtle mucosal changes with the assistance of different colors, which can detect not only bronchogenic carcinoma in situ but also non-malignant lesions such as metaplasia (16). Japanese research firstly performed AFI in TO, which revealed that the entire circumference of the pathological trachea was in a magenta color while the normal lobar and segmental airways appeared green (17). AFI maybe an appropriate tool to assess the management and follow-up of patients with TO, which can be an important supplementary approach to conventional bronchoscopy. More investigation need to be done about application of AFI in TO.

So far there are no standard guidelines for TO management. Some patients may not need to be over-treated as researchers found that some individuals had experienced a stable and non-progressive course as long as 20 years after diagnosis (18). Long-term clinical observation may be a good choice for patients at stage I. In Zhu’s opinion, inhaled corticosteroids might have some impact on patients at Stage I/II (2). Inhaled corticosteroids may be given chronically and regularly especially in those lesions filling with inflammatory cells, because lesions in the airway could not be completely corrected, and airway obstruction could not be reversed. Bronchoscopic intervention, such as argon plasma coagulation, radiofrequency ablation, may be vital for patients in stage II and stage III. Li believed that radiofrequency ablation could be applied to patients with scattered nodules due to its safety and less damage to deep tissue, and argon plasma coagulation may be used to patients with diffuse (widespread) or nodular (concentrated nodules) for its less smoke, less heat conduction and thinner eschar (19). The course and dose of inhaled corticosteroids, the interval of bronchoscopic intervention are still unclear because the limitations of retrospective study with small sample size. Large multicenter prospective study needs to be done to provide new sights about TO.

Conclusions

In conclusion, TO is a benign rare disease progressing slowly over years. Awareness is the key for diagnosis and management of TO, which needs multi-disciplinary cooperation of clinical, radiologist, endoscopic and histological assessment as well. Inhaled corticosteroids and bronchoscopic intervention may be two significant methods for TO treatment. The stage of TO based on bronchoscopic visualization might be applied to guide the choice of clinical treatment strategy.

Acknowledgments

The authors thank the patients and investigators for their participation in this study. The authors thank the colleagues in the Department of Pathology from The First Affiliated Hospital of Air Force Medical University, who gave lots of help about pathology.

Funding: This study was funded by national public health project (201402024).

Footnote

Reporting Checklist: The authors have completed the STROBE reporting checklist. Available at http://dx.doi.org/10.21037/apm-20-316

Data Sharing Statement: Available at http://dx.doi.org/10.21037/apm-20-316

Peer Review File: Available at http://dx.doi.org/10.21037/apm-20-316

Conflicts of Interest: All authors have completed the ICMJE uniform disclosure form (available at http://dx.doi.org/10.21037/apm-20-316). Nobody serves as an unpaid editorial board member (or Section Editor) of Annals of Palliative Medicine. The authors have no conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. The trial was conducted in accordance with the Declaration of Helsinki (as revised in 2013). This study was approved by the ethics committee of The Second Affiliated Hospital of Air Force Medical University (No.2013027). All of the subjects signed the informed consent form before they underwent bronchoscopic inspection. Because of the retrospective nature of the study, informed consent on human research was not obtained from the participants. Waiver of consent to use the patient records was granted by the Institutional Review Board, and analysis of this study was carried out after anonymization of the patients’ data.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.
