Necrotizing fasciitis of the jaw, neck and mediastinum caused by Klebsiella oxytoca and Streptococcus constellatus: a case report

Introduction

Necrotizing fasciitis (NF) is a rare, life-threatening infectious disease characterized by deep and superficial fascial necrosis, with rapid onset and rapid progression. It generally occurs in the perineum, groin and extremities, rarely in the head and neck (1). The complications of NF in the neck are serious and the mortality rate is relatively high (2). Hemolytic Streptococcus A, Staphylococcus spp. is the most common causative agent of NF. However, we reported a recently successfully treated case of severe NF that occurs around the face, neck, and mediastinum which is caused by rare pathogens (Klebsiella oxytoca and Streptococcus constellatus). The case will help us to have more clinic experience and create early-stage diagnostic standard and anticipate the severance of the case. And it will allow us to choose the correct treatment on this disease and other complication associated.

We present the following article in accordance with the CARE reporting checklist (available at http://dx.doi.org/10.21037/apm-20-2427).

Case presentation

The patient, male, 48 years old, was admitted to the department of ENT on 17 March 2020 with symptoms “4-days sore in left throat: and half day dysphagia and fever”. He had experienced cold and fatigue without toothache. Patient had also 10 years diabetes history with unstable control with insulin. During his check in patient had below condition: temperature: 38.5 °C, heart rate: 108 bpm, blood pressure: 130/80 mmHg, breathing 20 beats/min. Clear consciousness, restricted mouth open ability (1 transverse finger); Lower left side with no teeth or only roots left; 2^nd degree swelling on left side tonsil; Obvious swelling of the soft palate and palatal tongue arch on the left side, inaccessible to observe condition of epiglottis, larynx and pharynx; congestion of the skin in the parotid area, submaxillary area and upper left neck mild swelling with tenderness. The blood test result: leukocytes count 16.64×10⁹/L, neutrophils percentage 85.8%; C-Pr 320 mg/L; urinary routine: urine glucose (+++++), ketone bodies (+++++); fasting glucose metabolism: glucose 21.33 mmol/L, glycosylated albumin 47.67%. Normal liver and kidney function, negative screening for human immunodeficiency virus (HIV) and syphilis. Originally was considered as peritonsillar abscess with neck space infection disease. Puncture was performed to extract pus, but no pus was extracted. Cefathiamidine, metronidazole and insulin were injected to reduce blood glucose level and patient was rehydrated for ketoacidosis.

On the second day of admission, patient’s symptoms worsened, he was apathetic, sleepy with heart rate of 110/min. Patient had difficulty to breath and swelling was getting worse on the left parotid area, submandibular and upper neck, skin temperature increased, and was feeling twisting (Figure 1A). Patient was provided oxygen inhalation and was under ECG monitoring. CT scan was performed to check head and neck areas including left oropharyngeal lateral wall, left facial parotid area, both sides of submandibular, left neck and upper mediastinal pneumoperitoneum (Figure 1B,C). Patient also had ketoacidosis symptom (blood analysis results: PH 7.31, CO2 partial pressure 20 mmHg, oxygen partial pressure 77 mmHg, bicarbonate concentration 10.1 mmol/L, standard bicarbonate 13.9 mmol/L), change of sepsis (procalcitonin 8.73 ng/mL, reference value 0.5–10 ng/mL for consideration of sepsis). During that night tracheotomy, neck incision and drainage were performed. During the surgery, a transverse incision was made under the right jaw, and taupe pus with smell was extracted from the area of subhyoid muscles. There was smell but no obvious pus observed from left anterior edge of sternocleidomastoid muscle to the peri-carotid artery sheath area, until the upper level of the tip of the mastoid process and lower level of the posterior area of the clavicular head. During the operation, the two incisions were connected in the subcutaneous space. 2 negative pressure drainage tubes and nasogastric feeding tubes were inserted before patient was sending to SICU for monitoring

Figure 1 Preoperative frontal view, preoperative coronary CT (computed tomography) and preoperative sagittal CT. (A) Preoperative frontal view: significant swelling in the left parotid area, submandibular, upper neck. (B) Preoperative coronary CT: left parotid area, submandibular, lower neck air-containing pus cavity (arrow). (C) Preoperative sagittal CT: left fundus, submandibular, upper mediastinal air-bearing.

Next day after surgery, patient’s temperature reached 40 °C, and the swelling of the left side of the jaw and face was still obvious. Re-examination of the chest CT shows no improvement of gas build on the upper mediastinum and the left parotid area. So we rechecked through incision on the left neck, and a large amount of taupe pus with smell was drained from the anterior and subcutaneous space of the parotid gland. Pseudomembranous necrosis of the anterior muscular fascia was also observed, after cleaning the extracted tissue was sent for pathology check (Figure 2A); when we check the left side of mouth, mouth open ability was still limited, bottom of tongue was still swelling, ulceration and pus discharge at the left sublingual caruncle (Figure 2B); deep abscess was observed and connected to left parotid space neck space. Same type of pus was drained from left subcutaneous of left tracheotomy incision and upper mediastinum. After we left neck incision upper area open (Figure 2C); and drained pus under negative pressure from left bottom of mouth left neck incision. And clean abscess with hydrogen peroxide and diluted polyvinyl iodide solution.

Figure 2 Pathological sections, clinical features and pictures of pathogenic bacteria of the patient. (A) Pathology: HE (hematoxylin-eosin staining, HE) ×200, fascial necrosis and massive inflammatory cell infiltration. (B) Pus cavity rupture via the left sublingual caruncle. (C) After the second postoperative trauma: dark red, swollen skin in the left parotid area, open drainage port. (D) Klebsiella oxytoca: growth on blood plate, forming large greyish-white, moist, mucus-like colonies. (E) Streptococcus constellatus: white, round, β-hemolytic ring colonies on blood plates incubated at 35 °C.

Two pus cultures were sent for examination. The first pus culture sample was collected during the first surgery. The second pus culture sample was collected during the second surgery with trauma probe. The two pus cultures were both positive for Klebsiella oxytoca (Figure 2D) and Streptococcus constellatus (Figure 2E). Anaerobic cultures were negative for both pus and high fever blood. One week after treatment, pus and blood cultures showed fungal infection (Candida albicans and Candida guilliermondii). Before the bacterial culture results, based on experience, vancomycin, piperacillin sulbactam and ornidazole were used together, then adjusted to different antibiotic: meropenem and tigecycline, and fluconazole was used for fungal treatment. Throughout the entire treatment, glucose level was monitored and controlled by using insulin. Patient was rehydrated for ketoacidosis, nasal feeding and albumin supplementation were also used to treat his hypoproteinemia.

9 days after his surgery, patient temperature returned to normal. And from the 14^th days of admission to hospital, neck and oral pus decreased, and his mouth open ability improved as well. On the 25^th day with the 3^rd cleaning of wound, left neck incision was sutured. Only one negative pressure drain tube was left at the left front parotid gland abscess. On the 30^th day, negative pressure drain was removed. And patient was discharged from hospital on day 37. And according to patient’s follow up visits after 3 months, 6 months and one year there was no recurrence.

All procedures performed in the studies involving human being as participants were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient families.

Discussion

NF is dangerous and rare disease with an incidence of 0.004% to 0.001% (3), but there is a trend of increasing incidence worldwide. In the NF case, we presented, the situation was very severe, NF occurred extensively between shallow and deep fascial stroma. While it is more rarely that the case also impacted the maxilla, neck and mediastinum. NF pathogens are mostly mixed bacterial infections (4,5). Hemolytic Streptococcus A and Staphylococcus spp are the most common pathogens that cause NF. Recently, Klebsiella pneumoniae has been found as a cause of NF (6).

In this case, the mixed infection of Klebsiella oxytoca and Streptococcus constellatus constellation is rare. Klebsiella oxytoca is part of enterobacteriaceae family which is gram stain negative and facultative anaerobes. These bacteria can ferment glucose and produce acid and gas. Diabetic patient’s high-level glucose served as raw material in this case. So the CT result showed in this case showed a large amount of cumulated gas. In recent years, Streptococcus constellatus as a part of Streptococcus milleri family has gradually became one of the important pathogens causing purulent infections in the body with a few reports (7). Although it is aerobic Gram-positive, the anaerobic environment can increase its ability to grow. And co-infected with other bacteria its virulence can increase significantly. The patient had several negative anaerobic cultures of pus and blood, but both bacteria have alibility to multiple quickly under anaerobic conditions. The patient clinical condition is very typical anaerobic bacteria infection, showing gas and smell. The presence of Candida in the blood and pus cultures one week after treatment, we consider that it is related with using large dose of different types of antibiotics, not the original pathogen.

NF occurs well in adults with immune deficiencies such as diabetes (8). Dentinogenic infections are the most common cause of cervical NF, followed by parapharyngeal interstitial and peritonsillar infections (9). In this case, the patient was a diabetic patient with unstable control and low immunity. His early symptom was one side infection around tonsils. His late symptom was severe abscess around parotid gland and bottom of the tongue. And ulcerated is presented from the sublingual caruncle. Although patient doesn’t have tool extraction and toothache history, but left side teeth having cavities and missing teeth with only root. So we consider the cause of his NF infection is by teeth infection.

CT examination is essential in NF diagnosis and is one of the reliable methods of diagnosis and follow up (10). CT imaging of the neck NF includes: loss of fat shadow in in the interstices of the neck, thickness increasing of the cervical broad muscle, partial fractur of cervical broad muscle, fluid and gas accumulation in the deep cervical fascia and pneumoperitoneum. The typical sign of NF image is “Bubble sign” (11). Pathology is one of the standards for the diagnosis of NF, usually necrosis of the fascia and thrombosis of small vessels will be observed. In the case studied, the pathology conforms (Figure 2A).

Early-stage diagnosis of NF is very important, according to our experience, the following: (I) patients with low immunity such as unstable control of diabetes; (II) pharynx or dental infections are as inducement; (III) the disease progresses rapidly; (IV) neck swelling and pain, subcutaneous twirling feeling, apathetic; (V) in CT examination, there was swelling and effusion in fascial space, especially with “Bubble sign”.

The basic principle of treating NF is to make timely and extensive incision, repeatedly and thoroughly clear the trauma, and establish an unobstructed drainage (12). Most patients with NF have diabetes or ketoacidosis situation. We need to monitor patient closely and treat all complications then have surgery as soon as possible. The incision around neck area is challenging as it should be large and deep enough to clear necrotic facial tissue. But neck tissue is complicated, it contains important structure as carotid artery, trachea, esophagus, nerves… Overtreatment can damage these structures and be fatal. Also, before effectivity of antibiotics, the condition could get worse. It may need extra 2 or more surgeries according to the patient’s condition. In our case the patient worse condition was on day 3 after the surgery, further necrosis was presented. There was totally 3 times surgery to clean and drain It is also mentioned that after incision and drainage, combined with negative pressure suction, can strengthen the effect of cleaning and drainage.

In addition, the maintenance of airway patency is the top priority during the treatment of NF in the head and neck, and timely and necessary tracheotomy is an important part of the steps during treatment, which can prevent the occurrence of asphyxia. Early tracheotomy should be considered in patients with moderate to severe laryngeal obstruction and difficulty in opening the mouth; postoperative tissue swelling is aggravated by intraoperative pulling and injury to the cervical gap and upper mediastinal tissue, which can compress the airway, and prophylactic tracheotomy Pressure on airway can prevent pulling and injury to the cervical gap and upper mediastinal tissue and avoid aggravation of swelling condition. Preventive tracheotomy should also be performed before surgery. In this case, our patient is in a typical situation, so tracheotomy was performed before surgery.

According to relevant literature, although the mortality rate of NF is relatively high, but there is almost no recurrence of NF reported after cure, and the patient in this case also had no recurrence within 1 year of follow-up. Also, we considered that the patients will pay more attention to their heath after being saved.

In conclusion, NF at the head and neck area is rare and dangerous and is often with several bacterial infections. In this case it is much less common with two bacteria (Klebsiella acidophilus and Streptococcus zoster). Neck swelling and pain, subcutaneous crepitation, apathetic, are early-stage symptoms for diagnosis. Imaging, especially CT, is most helpful for diagnosis and evaluate treatment, and incisional examination of extensive fascial necrosis and pathology check after surgery are also accurate diagnosis standard. Early-stage diagnosis and positive treatment, keeping airway unobstructed, adjustment of antibiotics according to test result of culture and CT scan, debridement by stages, prevention and treatment of complications are the key therapy.
